VRLA AGM Battery

CPSY® is a large-scale 2V VRLA AGM battery manufacturer and supplier in China. We have been specialized in lighting for many years. Our products have a good price advantage and cover most of the European and American markets. We look forward to becoming your long-term partner in China.

Send Inquiry

Product Description

CPSY® VRLA AGM battery

As the professional manufacturer, we would like to provide you VRLA AGM Battery. The CPSY® 12V/2V VRLA AGM battery is the most popular reserve power design because the electrolyte is captive, preventing it from spilling even when the case is punctured.VRLA AGM batteries are considered "maintenance free" and require no addition of electrolytes or water. Styles of sealed VRLA batteries include front-access telecom cells as well as high-rate UPS replacement batteries. General purpose SLAs are also produced for emergency lighting and other applications.

CPSY® GP11 series Single Phase Low frequency ups Parameter (Specification)

MODEL NO. Voltage Capacity Dimension (mm) Weight (kg) Bolt
(V) (Ah) Length Width Height Total Height (±3%)
GW02200 2 200/10HR 170 106 330 367 13 M8×16
GW02300 2 300/10HR 171 151 330 365 18.5 M8×16
GW02400 2 400/10HR 211 176 329 367 26.1 M8×16
GW02500 2 500/10HR 241 172 330 364 31 M8×16
GW02600 2 600/10HR 301 175 331 366 37.7 M8×16
GW02800 2 800/10HR 410 176 330 365 51.6 M8×16
GW021000 2 1000/10HR 475 175 328 365 62 M8×16
GW021200 2 1200/10HR 472 172 338 355 68.5 M8×16
GW021500 2 1500/10HR 401 351 342 378 96.5 M8×16
GW022000 2 2000/10HR 491 351 343 383 130 M8×16
GW022500 2 2500/10HR 712 353 341 382 180 M8×16
GW023000 2 3000/10HR 712 353 341 382 190 M8×16

CPSY® GW02 series 200Ah~3000Ah VRLA AGM battery Feature And Application

CPSY® GW02 series 200Ah~3000Ah VRLA AGM battery

Model No.:GW02200-GW023000

Battery capacity range: 200Ah~3000Ah

General Features

-Sealed and maintenance free operation;

-Non-Spillable construction design;

-ABS containers and covers(UL94HB, UL94V-0) optional;

-Safety valve installation for explosion proof;

-High quality and high reliability;

-Exceptional deep discharge recovery performance;

-Low self discharge characteristic;

-Flexibility design for multiple install position


30% more cyclic life through innovation at the PAM additives

Long life expectancy of 10 years in floating condition

Thick flat plate with high Tin low Calcium alloy

Wide operating temperature range from -20 °C to 50°C

3% Low self-discharge rate

Very good deep cycle performance: up to 500 cycles @80% DOD

Excellent deep discharge recovery capability


Solar and wind Powe System
Cable TV
Marine Equipment
Electrical Toys
Military Equipment
Emergency lighting
Power Plants
Medical Devices
Golf Cart
Emergency Alarm Systems

Battery Use and Maintenance:

1) Please use constant-voltage charge.

2) In floating charge, the voltage is 2.23 to 2.27 per unit cell.

3) In cycle use, the voltage is 2.35 to 2.45 per unit cell, the max.Current is no more than 25C

4) Please do tighten the bolts to avoid sparkle and poor contact when the battery is in use.

5) Please do not use it near the heat source and open flame.

6) Please keep it at low temperature. Please change it while there is liquid leaking or damage.

CPSY®GW02 series 200Ah~3000Ah VRLA AGM battery Details

2 Volt Modular Battery Systems 200 - 3000 AhAGM battery for modular battery systems

The 2 Volt batteries have a similar design as the classic AGM batteries, however, they are built-in cases that are taller and thinner allowing a more compact footprint, especially in larger Ah systems.

This 6V SLA battery is an AGM (absorbent glass mat), maintenance-free, valve-regulated (VRLA), rechargeable battery. Able to be used with a wide variety of applications; the 6V SLA battery has a wide operating temperature, long service life and deep discharge recovery.

Meets or exceeds the OEM sealed lead acid battery specifications.

We supply only brand-new, factory fresh, high quality batteries.

These batteries are completely spill proof and leak proof.

The key to this battery technology is the porous glass mat separators, which completely absorb and trap electrolyte (battery acid).

6V SLA battery arrives fully charged, ready to go.

When compare with peers, CPSY® 2V, 6V, 12 V complete series 7Ah~3000Ah VRLA AGM battery advantages as below:

1. High quality, high reliability

2. Long service life

3. No free electrolyte, no corrosive gas leak, no pollution to the environment, comprehensive environment-friendly

4. Silver-plated copper terminals, excellent electrical conductivity, beautiful appearance

5. Can be deep discharge, resistant to overcharge and over discharge

6. Wide temperature range (-40º ~ + 60º)

7. Special sealed design, never leak the electrolyte, the use of safe, three-dimensional direction can be used

8. Battery discharge to zero voltage for 1 month, the charge can be restored

9. Self-discharge is small, less than 3% per month, long shelf life, storage 2 years does not fail


15–20 year design life at 77° F

Cycle life at 77° F

1200 cycles @ 80% DOD

2250 cycles @ 50% DOD

100% capacity upon delivery

Maintenance free — no watering required

No corrosive fumes — special battery room not required

Seismic modular racking

Tank formed plates provide consistent and stable voltages

Extra space in jars for grid growth to enhance battery life

UL Listed - UL file no. MH19767

Application:Communication, Traffic, IT, Financial, UPS, Solar, Radio, Electric Power, Data Centre, Aviation, Home, Electrocar, etc

Certification:CE / UL / ISO9001 / Rohs

High-strength ABS plastic battery slot and cover, compact structure. good resistance.

Special lead-based multi-alloy grid, with small internal resistance and corrosion resistance.

good opacity, strong charge acceptance.

New electrode plate manufacturing process, high utilization rate of active materials.

Multi-layer sealing technology and special sealing glue ensure that the battery has no leakage, no acid mist .


- Don't put the battery exposure or lost in the fire.

- Don't make the wrong terminals connected when charging.

- Avoid battery short circuit.

- Avoid excessive physical shock or vibration.

- Don't disassemble or deform the battery.

- Keep out of the reach of children.

- Never use a modified or damaged charger.

- Store the battery in a cool, dry and well-ventilated area.

- Regulations vary in different countries, dispose of in accordance with local regulations




Oil & Gas

Solar / Photovoltaic


Emergency Lighting

Railways/railway signals

Alarm panels

UPS Backup

Electric power systems,

Emergency backup power supply,

Emergency lighting,

Aircraft signals

Communication power supply

Gate operator equipment and solar
